Vinz' Blog (ProudMonkey) "Code, Beer and Music ~ my way of being a programmer"

A developer is asking how to pass data from a UserControl control to the main page. Basically, the scenario is that he has a user control which contains a GridView and wrap arround within asp Ajax UpdatePanel control. The UserControl will then be used at the page that is hosted within a master page. The page contains some TextBox in which it will be populated once the user selects a row from the GridView also on that page the Modalpop is defined.

To achieve that, here's one solution I've provided to the developer.

The Page markup:


<%@ Page Title="" Language="C#" MasterPageFile="~/Site.Master" AutoEventWireup="true" CodeBehind="Modal.aspx.cs" Inherits="WebAppDemo.Modal" %>

<%@ Register Assembly="AjaxControlToolkit" Namespace="AjaxControlToolkit" TagPrefix="asp" %>
<%@ Register src="UserControl/WebUserControl1.ascx" tagname="WebUserControl1" tagprefix="uc1" %>

<asp:Content ID="Content1" ContentPlaceHolderID="HeadContent" runat="server">
    <style type="text/css">
        .modal-bg{
            background-color:Gray;
            filter:alpha(opacity=50);
            opacity:0.6;
            z-index:999;
        }
        .modal{
            position:absolute;
        }
    </style>

</asp:Content>
<asp:Content ID="Content2" ContentPlaceHolderID="MainContent" runat="server">
    <asp:ToolkitScriptManager ID="ToolkitScriptManager1" runat="server">
    </asp:ToolkitScriptManager>

    <asp:TextBox ID="txtProductName" runat="server" />
    <asp:TextBox ID="txtPrice" runat="server" />


    <asp:LinkButton ID="LinkButton1" runat="server" Text="Show" />
    <asp:Panel ID="pnlPopUp" runat="server" style="display:none" CssClass="modal" >
                    <uc1:WebUserControl1 ID="WebUserControl11" runat="server" />
    </asp:Panel>
    <asp:ModalPopupExtender ID="ModalPopupExtender1" runat="server" TargetControlID="LinkButton1" PopupControlID="pnlPopUp" BackgroundCssClass="modal-bg">
    </asp:ModalPopupExtender>

</asp:Content>

As you can see, there really no fancy about the markup above. It just contains two TextBox, ModalPopup, and UserControl within the panel and a LinkButton as the target control for the Modal.

UserControl markup:


<%@ Control Language="C#" AutoEventWireup="true" CodeBehind="WebUserControl1.ascx.cs" Inherits="WebAppDemo.UserControl.WebUserControl1" %>
<%@ Register Assembly="AjaxControlToolkit" Namespace="AjaxControlToolkit" TagPrefix="asp" %>

<asp:UpdatePanel ID="UpdatePanel1" runat="server">
   <ContentTemplate>
         <asp:GridView ID="GridView1" runat="server" AutoGenerateColumns="False">
                    <Columns>
                         <asp:BoundField DataField="ID" />
                         <asp:BoundField DataField="ProductName" HeaderText="Product Name" />
                         <asp:TemplateField>
                            <ItemTemplate>
                                <asp:TextBox ID="txtPrice" runat="server" Text='<%# Eval("Price") %>' />
                            </ItemTemplate>
                         </asp:TemplateField>
                         <asp:TemplateField>
                            <ItemTemplate>
                                <asp:TextBox ID="txtAmount" runat="server" Text='<%# Eval("Amount") %>' />
                            </ItemTemplate>
                         </asp:TemplateField>
                         <asp:TemplateField>
                            <ItemTemplate>
                                <asp:Button ID="Button1" runat="server" Text="Select" onclick="Button1_Click" />
                            </ItemTemplate>
                         </asp:TemplateField>
                    </Columns>
        </asp:GridView>
   </ContentTemplate>
   <Triggers>
        <asp:PostBackTrigger ControlID="GridView1" />
   </Triggers>
</asp:UpdatePanel>



CODE BEHIND:


using System;
using System.Collections.Generic;
using System.Linq;
using System.Web;
using System.Web.UI;
using System.Web.UI.WebControls;
using System.Data;
using AjaxControlToolkit;

namespace WebAppDemo.UserControl
{
    public partial class WebUserControl1 : System.Web.UI.UserControl
    {

        private DataTable GetSampleData()
        {

            //NOTE: THIS IS JUST FOR DEMO
            //If you are working with database
            //You can query your actual data and fill it to the DataTable
            DataTable dt = new DataTable();
            DataRow dr = null;

            //Create DataTable columns
            dt.Columns.Add(new DataColumn("ID", typeof(string)));
            dt.Columns.Add(new DataColumn("ProductName", typeof(string)));
            dt.Columns.Add(new DataColumn("Price", typeof(string)));
            dt.Columns.Add(new DataColumn("Amount", typeof(string)));


            //Create Row for each columns
            dr = dt.NewRow();
            dr["ID"] = 1;
            dr["ProductName"] = "Galaxy S";
            dr["Price"] = "100";
            dr["Amount"] = "10";

            dt.Rows.Add(dr);

            dr = dt.NewRow();
            dr["ID"] = 2;
            dr["ProductName"] = "iPhone 4";
            dr["Price"] = "200";
            dr["Amount"] = "2";

            dt.Rows.Add(dr);

            dr = dt.NewRow();
            dr["ID"] = 3;
            dr["ProductName"] = "HTC Mobile";
            dr["Price"] = "50";
            dr["Amount"] = "10";

            dt.Rows.Add(dr);
            return dt;
        }

        private void BindGrid(DataTable source)
        {
            GridView1.DataSource = source;
            GridView1.DataBind();
        }
        protected void Page_Load(object sender, EventArgs e)
        {
            if (!IsPostBack)
                BindGrid(GetSampleData());
        }

        protected void Button1_Click(object sender, EventArgs e)
        {
            Button b = (Button)sender;
            GridViewRow gvRow = (GridViewRow)b.NamingContainer;

            string productName = gvRow.Cells[1].Text;
            string price = ((System.Web.UI.WebControls.TextBox)gvRow.FindControl("txtPrice")).Text;

            Type thePage = Page.GetType();
            System.Reflection.PropertyInfo[] pi = thePage.GetProperties();
            foreach (System.Reflection.PropertyInfo pinfo in pi)
            {
                if (pinfo.Name == "ProductName")
                {
                    pinfo.SetValue(Page, productName, null);
                }
                else if (pinfo.Name == "Price")
                {
                    pinfo.SetValue(Page, price, null);
                }
            }

            ((ModalPopupExtender)this.Parent.Parent.FindControl("ModalPopupExtender1")).Hide();

        }
    }
}



As you can see at the Button.Click event I have used reflection to get the reference to the control from the main page and the set the needed values that I need to pass in the main page.

Running the page will display something like this:


On initial load:

After clicking the "show" link

After selecting the second row in the gridview





That's it! I hope someone find this post useful!

Posted on Friday, September 2, 2011 8:57 PM ASP.NET | Back to top


Comments on this post: Masterpage, User Control, Modal Popup and Update Panel - Passing values to parent page.

# re: Masterpage, User Control, Modal Popup and Update Panel - Passing values to parent page.
Requesting Gravatar...
Hi, I need to implement something exactly similar to the one you mentioned. But you havent mentioned how to access the values in the parent page that is the aspx page.

So, I tried my self on the page load event of the parent page , it didnt worked. Then I tried in OnPreRender Event then it worked. Just wanted to let you know.
Thank you for sharing this functionality. Bless you :) :)
Left by ItsMe on Oct 14, 2011 7:22 AM
